MSI Vector 16 HX AI A2XWHG-411XCZ

MSI Vector 16 HX AI A2XWHG-411XCZ Core Ultra 7 255HX/16GB/1TB SSD/RTX 5070 Ti, 12GB/16"FHD+ IPS,144Hz/bez OS/černá

Part No 9S7-15M352-411

SKU Number

Website Name Vector 16 HX AI A2XWHG

Brand MSI

Platform INTEL

Series Name Gaming

Segment Name Vector

Segment Name2 Vector16HXAIA

Segment Name3 Vector16HXAI A2XWHG

Model 15M3

MKT Name Vector 16 HX AI A2XWHG

Entity MKT Name

MKT Spec Vector 16 HX AI A2XWHG-411XCZ

System/Barebone System

Chassis Color

Color ID5(GG)/Cosmos_Gray-Black-Cosmos_Gray-Cosmos_Gray

Color_Website Cosmos Gray

Chassis Material

A Side Metal

B Side Plastic

C Side Plastic

D Side Plastic

Display

Screen Size 16

Resolution IPS-Level FHD+

Pixel 1920x1200

LCD Features ANTI-GLARE

Screen Touch Non-touch

Frame Rate 144Hz

Response Time Tr+Tf 20ms

Color Range 45%

Screen Size_Website 16"

Pixel_Website FHD+(1920x1200)

Frame Rate_Website 144Hz Refresh Rate

Color Range_Website N/A

Display Type_Website IPS-Level

HDR Value N/A

Touch Feature_Website NA

Brightness 350 nits

CPU

CPU Type 20 CORE

CPU Core Name ARROW LAKE

CPU Socket FCBGA-2114pin

CPU Number Core Ultra 7 255HX

CPU Clock 2.4GHz

CPU Cores 20

CPU Core Name_Website N/A

CPU Number_Website Intel® Core™ Ultra 7 processor 255HX with Intel® AI Boost (NPU)

CPU Number_Website For GC Intel® Core™ Ultra 7 processor 255HX with Intel® AI Boost (NPU)

CPU Specification_Website 20 cores (8 P-cores + 12 E-cores), 20 thread, 36MB cache, Max Turbo Frequency 5.2 GHz

Chipset

Chipsets HM870

Chipset SoC_Website Intel® HM870

Discrete Graphics

GPU1 Vendor NVIDIA

GPU1 MKT Name GeForce RTX5070 Ti

GPU1 Number RTX 5070 Ti

GPU1 MKT Name_Website NVIDIA® GeForce RTX™ 5070 Ti Laptop GPU powers advanced AI with 992 AI TOPS

GPU1 Boost Clock_Website "Up to 2220MHz Boost Clock 140W Maximum Graphics Power with Dynamic Boost. *May vary by scenario"

GPU1 Remark_Website N/A

CPU and GPU Combined Power

Combined Power_Website Max. 205W CPU-GPU Power with MSI OverBoost Ultra Technology.

OverBoost Ultra Remark_Website N/A

Scenario Remark_Website NA

Cooling

Thermal Cooler Boost 5

Fan 2

Fan Technology N/A

Pipe 6

Vapor Chamber N/A

Video Memory

GPU1 VRAM Size 12GB

GPU1 VRAM Type GDDR7

Integrated Graphics

GPU1 Graphics_Website Intel® Graphics

Memory

Memory Size 8GB*2

Memory Module DDR5-5600

Memory(Slot) Max Speed Up to DDR5-6400

Memory Form NA

Memory Remark_Website *The actual frequency will vary by memory combination and CPU capability.

Memory Slot and Max Capacity

Memory Max Speed Up to DDR5-6400

Memory Slot 2 Slots

Memory Max Capacity_Website Max 96GB

Storage

SSD Form Factor M.2-2280 M-KEY

SSD Size 1TB*1

SSD Interface NVMe SSD PCIe Gen4

HDD1 Interface N/A

HDD1 Form Factor N/A

SSD Gen_Website NVMe SSD PCIe Gen4

HDD size N/A

HDD1 RPM N/A

ODD Type N/A

Multi Bay N/A 2.5" HDD_Website N/A

SSD Remark ”Please consult service center for upgrading SSD.”

Storage Slot

SSD (NVMe PCIe Gen)_Website 1x M.2 SSD slot (NVMe PCIe Gen4), 1x M.2 SSD slot (NVMe PCIe Gen5) Compatible

HDD_Website NA

LAN

LAN_Website 2.5 Gigabit Ethernet

LAN REALTEK/RTL8125BG-CG

RJ45 1x

Wi-Fi/ Bluetooth

WLAN/BT_Website Intel® Wi-Fi 6E AX211, Bluetooth v5.3

WLAN Version Wi-Fi 6E+BT

WLAN/BT INTEL/AX211.NGWG.NV

I/O Ports

Audio Line In NA

Audio Line Out NA

Digital out SPDIF NA

USB Ports

Type-C (USB3.1 Gen2 / DP / Thunderbolt™3) NA

Type-C (USB3.1 Gen2 / DP / Thunderbolt™3 optional) NA

Type-C (USB3.2 Gen2 / DP / Thunderbolt™3) NA

Type-C (USB3.2 Gen1 / DP / Thunderbolt™3) NA

Type-C (USB3.2 Gen2 / DP / Thunderbolt™3) with PD charging NA

Type-C (USB3.2 Gen2 / DisplayPort™) NA

Thunderbolt™ 4 (DisplayPort™/ Power Delivery 3.0) NA

Thunderbolt™ 4 (DisplayPort™/ Power Delivery 3.1) NA

Thunderbolt™ 4 (DisplayPort™) NA

Thunderbolt™ 5 (DisplayPort™/ Power Delivery 3.1) 2x

Thunderbolt™ (DisplayPort™/ Power Delivery 3.0) NA

Type-C (USB4® / DisplayPort™/ Power Delivery 3.0/ Thunderbolt™ 4 compatible) NA

Type-C (USB4® / DisplayPort™/ Power Delivery 3.1/ Thunderbolt™ 4 compatible) NA

Type-C (USB3.2 Gen2 / DisplayPort™/ Power Delivery 3.0) NA

Type-C (USB3.2 Gen2 / DisplayPort™/ Power Delivery 3.1) NA

Type-C (USB3.2 Gen1 / DisplayPort™/ Power Delivery 3.0) N/A

Type-C (USB3.1 Gen1 / DisplayPort™) NA

Type-C (USB3.2 Gen1 / DisplayPort™) NA

Type-C USB3.1 Gen2 NA

Type-C USB3.2 Gen2 NA

Type-C USB3.2 Gen2 with PD charging NA

Type-C USB3.1 Gen1 NA

Type-C USB3.2 Gen1 NA

Type-A USB3.1 Gen1 NA

Type-A USB3.2 Gen1 NA

Type-A USB3.1 Gen1/ QC3.0 NA

Type-A USB3.2 Gen1/ QC3.0 NA

Type-A USB3.1 Gen2 NA

Type-A USB3.2 Gen2 2x

Type-C USB3.2 Gen2x2 NA

Type-A USB3.1 NA

Type-C USB3.0 N/A

Type-A USB3.0 NA

Type-A USB2.0 NA

USB3.2 Gen 2 Type-C(connect to computer) NA

Card Reader

CardReader 1x SD Express

Smart Card Reader NA

Video Ports

VGA Out NA

HDMI™ 1x HDMI™ 2.1 (8K @ 60Hz / 4K @ 120Hz)

DisplayPort NA

Mini Display Port NA

Keyboard

Keyboard Types_Website 24-Zone RGB Gaming Keyboard with Copilot Key

Keyboard Keys 99KEYS

Keyboard Backlit Y

Keyboard Numeric Yes

Keyboard Color BLACK

Keyboard Language CS Wleft Nokr

Touchpad

Touchpad Silky Smooth Touchpad

WebCam

WebCam IR FHD type (30fps@1080p) with HDR

Webcam Feature 3D Noise Reduction+ (3DNR+)

Audio Port

Audio Jack_Website 1x Mic-in/Headphone-out Combo Jack

Audio

Audio Speaker 2x 2W

Audio Woofer NA

Audio Mic Array Microphone

Audio Solution_Website Nahimic 3 Audio Enhancer, Hi-Res Audio Ready

AC Adapter

Adaptor Output 330W adapter

Adaptor 330W

Adaptor Input 90-264Vin

Adaptor Unit Weight (g) 1050

Power Cord Unit Weight (g) 195

Battery

Battery Type 4CELLS/4S1P

Battery Cell_Website 4-Cell

Whrs 90 Whrs

Mah 5845 Mah

Battery Unit Weight (g) 367.8

Operating Systems

OS N/A

OS Type Free DOS

OS_Website Free Dos

Copilot+ PC Certified NA

Microsoft Office

OS-Office_Website N/A

Dimension (WXDXH)

Dimension 357 x 284 x 22.20-28.55 mm

Dimension(Inches)_Website 14.06" x 11.18" x 0.87-1.12"

Weight (W/ Battery)

Weight 2.7 kg

Weight(lbs)_Website 5.95 lbs

Security

Security Type_Website "Firmware Trusted Platform Module(fTPM) 2.0

Webcam Shutter

Kensington Lock"

Certification

Certification Type_Website Meta Ready

Sustainability

EPEAT_Website N/A

Sensor

Fingerprint_Website NA

Fingerprint (Optional) NA

Ambient Light Sensor_Website NA

Gyroscope_Website NA

Accelerometer_Website NA

Magnetometer_Website NA

Proximity Sensor NA

NFC (Optional) NA

Warranty

Warranty 24M

Warranty_Website 2 years limited warranty

Xbox Game Pass

Xbox Game Pass N/A

Xbox Game Pass Remark N/A

Accessory

Accessory_Website

Extra Bag N/A

Extra Mouse N/A

Remark

I/O Ports Remark NA

Remark 1_Website

Remark 2_Website

Remark 3_Website

Remark 4_Website

Remark 5_Website

Software

Software Killer Control Center, Nvidia App, Nahimic 3, MSI App Player, Mystic Light, Crosshair, Battery Master, MSI Center, Discrete Graphics Mode, MSI AI Engine, AI Noise Cancellation Pro, Intel Application Optimization
